HPE PL DL380g11 4514Y (2.0/16C) 4x32G (P64706) NS204i-u(2x480g) 2x1000W 8SFF 2x10G-T Smart Choice
HPE PL DL380g11 4514Y (2.0/16C/30M) 4x32G (P64706-B21) NS204i-u(2x480gM.2) 2x1000W 8SFF 2x10G-T Smart Choice
SKU Number P52561-421
Model Name HPE ProLiant DL380 Gen11 4514Y 2.0GHz 16c 1P 128GB-R 8SFF NS204i-u NC BCM57416 2x1000W PS EU Server
Chassis 8SFF NC CTO Server (P52534-B21)
CPU 4514Y (16 core, 2.0 GHz, 150W)
Number of CPU One with standard heatsink
Memory 128 GB (4x32 GB, 5600 MT/s) Notes: Runs at 4400 MT/s due to processor limitation. 4x P64706-B21
Network Controller Broadcom BCM57416 Ethernet 10Gb 2-port BASE-T Adapter for HPE
Storage Controller HPE NS204i-u Gen11 NVMe Hot Plug Boot Optimized Storage Device (2x480G m.2)
Internal Storage 8-26SFF CTO Server (upgradeable to 24 SFF front + 2SFF rear)
PCIe Slots 3-slots (x8, x16, x8) as standard; upgradeable to 8-slots in a 2 processor configuration
Power Supply 2x HPE 1000W Flex Slot Titanium Hot Plug Low Halogen Power Supply Kit (-421)
Fans 6x High Performance Fan
Management HPE iLO 6
Security Trusted Platform Module (TPM) Notes: Enabling TPM 2.0 no longer requires TPM module option kit for Gen11. It is an embedded feature and can be disabled in the BIOS setting.
Rail Kit SFF Easy Install Rail Kit; cable management arm
Energy Star Energy Star 3.0
Form Factor 2U Rack
Warranty 3-year parts, 3-year labor, 3-year onsite support with next business day response.
| HPE ProLiant DL380 Gen11 - Smart Choice Models | |
| SKU Number | P77242-425 |
| Model Name | HPE ProLiant DL380 Gen11 4514Y 2.0GHz 16c 1P 128GB-R 8SFF NS204i-u NC BCM57416 2x1000W PS EU Server |
| Chassis | HPE ProLiant DL380 Gen11 8SFF NC Configure-to-order Server |
| Processor | 4514Y (16 core, 2.0 GHz, 150W) |
| Number of CPU | One |
| Memory | 128 GB (4x32 GB, 5600 MT/s) Notes: Runs at 4400 MT/s due to processor limitation. |
| Network | Broadcom BCM57416 Ethernet 10Gb 2-port BASE-T Adapter for HPE |
| StorageController | HPE NS204i-u Gen11 NVMe Hot Plug Boot Optimized Storage Device |
| Hard Drives | None ship standard, 8 SFF supported |
| Optical Drive | Optional DVD-ROM Optional via Universal Media Bay External support only |
| Expansion Slots | 3-slots (x8, x16, x8) as standard; upgradeable to 8-slots in a 2 processor configuration |
| Power Supply | 2x HPE 1000W Flex Slot Titanium Hot Plug Power Supply Kit |
| Fans | 6x High Performance Fan |
| Management | HPE iLO 6 |
| Rail Kit | HPE ProLiant DL3XX Gen11 Easy Install Rail 3 Kit |
| Security | TPM (Trusted Platform Module) |
.
